10/100 Mbps Multimode SC Media Converter COMMSCOPE/AMP (1591024-9)
- Part number: 1591024-9
- AMP Fast Ethernet Media Converter, 100BASE-FX, SC, MM.
Thông số kỹ thuật
| Standard | IEEE802.3, IEEE802.3u Ethernet @ 10/100 Mbps |
| Data Rates | 10 and 100 Mbps auto negotiation (option to force 10 Mbps for legacy ystems) |
| Duplex Mode | Full or half-duplex auto-negotiation and N-Way support |
| Max. forwarding rate | 14,880 packets per second (pps) @ 10 Mbps, 148,800 pps @ 100 Mbps |
| Copper Interface | Shielded RJ-45 port with Auto MDI/MDIX sensing |
| Fiber Connector | Multimode SC, ST or MT-RJ and singlemode SC |
| Fiber Types | Multimode 50/125µm, 62.5/125µm and singlemode 9/125µm |
| Fiber working range | 2km for multimode, 15km for singlemode |
| Optical Budget | 12dB multimode, 13dB singlemode |
| Optical wavelength | 1310nm |
| Forwarding method | Store-and-forward to separate the two collision domains |
| Flow control | Back-pressure and forward control |
| MAC table size | 4095 entries, auto aging and learning |
| Switch settings | Auto negotiation or fixed 10 Mbps operation Fiber link full or half duplex |
| LED Diagnostic indicators | - Power - UTP link activity - UTP full or half duplex - A19Speed (10/100 Mbps) - Fiber link activity - Fiber full or half duplex |
| Emissions | Complies with FCC Class A and CE Class A |
| Safety | UL, CE |
| Temperature range | 0° - 45° C with humidity 10% to 90% non-condensing |
| Mounting methods | Standalone or rack mountable in 19-inch enclosures |
| Dimensions (L x W x H) | 118 x 84 x 25 mm |
| Power consumption | 4 Watts maximum |
| Power | 5V DC using an external AC/DC power adapter |
