Máy photocopy màu FUJIFILM Apeos C3570
- Chức năng chuẩn: Copy/In mạng/Scan mạng màu - DADF - Duplex.
- Tốc độ copy/In: 35 trang/ phút (màu, đen trắng).
- Bộ nhớ: 4GB.
- SSD: 128GB.
- Độ phân giải in: 1200 x 2400 dpi.
- 04 khay nạp giấy chính: 4 x 520 tờ/khay.
- 01 khay giấy tay: 90 tờ.
- Khổ giấy A5 - A3.
- Bộ nạp và đảo bản gốc tự động (DADF) - Có sẵn.
- Bộ đảo bản sao tự động (Duplex).
- Giao diện điều khiển: LCD màu 10.1 inch.
- Chuẩn kết nối: Ethernet 10/100/1000Base-TX, USB3.0.
Đặc tính kỹ thuật
| Basic Specifications/Copy Function | |
| Type | Console |
| Memory capacity | 4 GB (Max: 4 GB) |
| Storage Device Capacity | 128 GB |
| Colour Capability | Full colour |
| Scan Resolution | 600 x 600 dpi |
| Printing Resolution | 1200 x 2400 dpi (Text-Photo / Photo), 600 x 600 dpi (Text / Map) |
| Warm-up Time | [Embedded Plug-ins / Custom Services] When enabled: 30 seconds or less (23 degrees Celsius room temperature) When disabled: 24 seconds or less (23 degrees Celsius room temperature) |
| Recovery Time (Recovery Time from Sleep mode) | 5 seconds or less (23 degrees Celsius room temperature) |
| Original Size | Maximum of A3, 11 x 17 inch, 297 x 432 mm for both Sheet and Book |
| Paper Size | Max: SRA3 (320 x 450 mm), 12 x 18 inch (305 x 457 mm), A3 [12 x 19 inch (305 x 483 mm), 320 x 483 mm when using Bypass Tray] |
| Min: A5, Postcard (100 x 148 mm) [89 x 98 mm when using Bypass Tray] | |
| Image loss width: Lead edge 4.0 mm, Trail edge 2.0 mm, Right/Left edge 2.0 mm | |
| Paper Weight | Paper Tray: 52 to 300 gsm Bypass Tray: 52 to 300 gsm |
| First Copy Output Time | B/W: 4.9 sec. Colour: 6.7 sec. |
| Continuous Copy Speed | A4 LEF/JIS B5 LEF: B/W: 35 ppm; Colour:35 ppm A4 / JIS B5: B/W: 27 ppm; Colour:27 ppm JIS B4: B/W: 23 ppm; Colour: 23 ppm A3: B/W: 19 ppm; Colour:19 ppm |
| Paper Tray Capacity | Standard: 4 Tray Model: 520 sheets x 4-tray + Bypass Tray 90 sheets Tandem Tray Model: 520 sheets x 2-tray + 840 sheets + 1230 sheets + Bypass Tray 90 sheets |
| Optional: High Capacity Feeder B1: 2000 sheets High Capacity Feeder B2: 2940 sheets |
|
| Max: 4 Tray Model: 5110 sheets (4 Tray Model + High Capacity Feeder B2) Tandem Tray Model: 6140 sheets (Tandem Tray Model + High Capacity Feeder B2) |
|
| Output Tray Capacity | Upper Center: 250 sheets (A4 LEF), Lower Center: 250 sheets (A4 LEF) |
| Power Supply | AC220-240 V +/- 10 %, 10 A, 50/60 Hz common |
| Maximum Power Consumption | 2.2 kW (AC220 V +/- 10 %) 2.4 kW (AC240 V +/- 10 %) Sleep mode: 0.5 W (AC230 V) Ready mode: 57 W (AC230 V) |
| Dimensions | W 633 x D 677 x H 1119 mm |
| Weight | 124 kg |
| Print Function | |
| Type | Built-in type |
| Continuous Print Speed | Same as the Basic Specifications / Copy Function |
| Printing Resolution | Standard: [PCL Driver] Standard: 1200 x 2400 dpi, High Quality: 1200 x 2400 dpi, High Resolution: 1200 x 1200 dpi |
| Optional: [Adobe® PostScript® 3TM Driver] High Speed (Standard): 600 x 600 dpi, High Quality: 1200 x 2400 dpi, High Resolution: 1200 x 1200 dpi |
|
| Page Description Language | Standard: PCL5 / PCL6 Optiona:l Adobe® PostScript® 3TM |
| Supported Operating System | Standard: [PCL Driver] Windows 10 (32 bit / 64 bit), Windows 8.1 (32 bit / 64 bit), Windows Server 2019 (64 bit), Windows Server 2016 (64 bit), Windows Server 2012 R2 (64 bit), Windows Server 2012 (64 bit) [Mac OS X Driver] macOS 11 / 10.15 / 10.14 / 10.13 / 10.12 |
| Optional: [Adobe® PostScript® 3TM Driver] Windows 10 (32 bit / 64 bit), Windows 8.1 (32 bit / 64 bit), Windows Server 2019 (64 bit), Windows Server 2016 (64 bit), Windows Server 2012 R2 (64 bit), Windows Server 2012 (64 bit) macOS 11 / 10.15 / 10.14 / 10.13 / 10.12 |
|
| Interface | Standard: Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T, USB3.0 Optional: Wireless LAN (IEEE 802.11 a / b / g / n / ac) |
| Scan Function (Optional) | |
| Type | Colour Scanner |
| Scan Resolution | 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 200 dpi |
| Scan Speed | Same as the Scan Speed for the Duplex Automatic Document Feeder |
| Interface | Standard: Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T Optional: Wireless LAN (IEEE 802.11 a / b / g / n / ac) |
- Bảo hành: 12 tháng.
