2.5G BiDi SFP Simplex LC SMF Transceiver Module RUIJIE 2.5G-SFP-LX03-SM1310-BIDI-I
- 2.5G BiDi SFP 1310nm-TX/1550nm-RX 3-km DOM Simplex LC SMF Transceiver Module.
- Max. power consumption 1W.
- Saving half fiber by using only one fiber for transmiting and receiving.
- Hot pluggable SFP MSA compliant.
- Digital optical monitoring capability for strong diagnostic capabilities.
- Compliant with IEEE 802.3z Gigabit Ethernet.
- Class 1 Laser safety and RoHS compliant.
Specifications
| Data rate | 3.125 Gbps |
| Form factor | SFP |
| Connector type | BIDI LC |
| Cable type | SMF |
| Fiber end face finish type | Ultra Physical Contact (UPC |
| Transmitter type | FB |
| Receiver type | PIN |
| Reach | 3 km (9,842.52 ft.) |
| Bit error ratio (BER) | 1.00E-12 |
| Data diagnosis-capable (DDM/DOM) | Yes |
| Power consumption | ≤ 1 W |
| Transmitter Optical Parameters | |
| Wavelength | 1310 nm TX 1550 nm RX |
| Max. transmit power (AVG) | –3 dBm |
| Min. transmit power (AVG) | –9 dBm |
| Min. extinction ratio | ≥ 6.5 dB |
| Receiver Optical Parameters | |
| Receive sensitivity (OMA) | < –16 dBm |
| Overload optical power (AVG) | –3 dBm |
| Environment and Reliability | |
| Operating temperature | –40ºC to +85ºC (–40ºF to +185ºF) |
| Operating humidity | 10% RH to 90% RH |
| Storage temperature | –40ºC to +85ºC (–40ºF to +185ºF) |
| Storage humidity | 10% RH to 90% RH |
| Dimensions and Weight | |
| Dimensions (W x D x H) | 56.5 mm x 13.5 mm x 8.5 mm |
| Weight | 35g |
- Bảo hành: 3 năm.
